CITY BUS – G03EV6 Electric City Bus
| Specifications | |
|---|---|
| Overall dimension(mm) | 12000×2550×3360 |
| Approaching/departure angle(°) | 7°/7° |
| Wheelbase(mm) | 6100 |
| Track (front/rear )(mm) | 2080/1860 |
| Seat capacity | Normal layout 30 Seated (Standing room available). Please note internal fit out can be customised to suit RUB/VDAM/council requirements |
| Front/rear overhang(mm) | 2570/3330 |
| Curb weight(kg)(approximate) | To be confirmed- dependant on requirements |
| Gross Vehicle Mass(kg) | 18000 (Can be driven on a NZ class 2 licence) |
| Motor model | ZF AVE 130(in-wheel motor) |
| Electric motor output | Peak torque: 22,000 Nm Continuous torque: 8200 Nm 2 x 125Kw (250kw total) |
| Electric motor specifications | 400 V (effective nominal voltage). 2 x Asynchronous motors, 3 phase, water cooled |
| Battery | 314kwh |
| Range | Up to 330km |
| Front axle | ZF RL85EC |
| Rear axle | ZF AVE 130 |
| Braking System | ZF (All Disc Brake) |
| ABS/EBS | WABCO ABS/EBS |
| Suspension System | Air suspension with ECAS, Kneeling |
| CAN Equipment | CAN BUS(ACTIA) |
| Steering System | 8098 power steering |
| Tyres | 275/70R22.5 6 tyres |
| Bus Body | Monocoque, 100% Electrocoated |
| A/C | Roof mounted type 32000kcal/h- fully electric |
| Electronic destination boards | Front, Side and rear mounted destination boards ,internal 38”LED screen near second door |
| Driver seat | Isrihausen ISRI6860NTS875 |
| Doors | Three (3) pneumatic inner swing aluminium doors, driver controlled |
| Lighting system | Twin line ceiling light, lighting around steps |
| Reverse monitor | LCD-screen reverse camera for the driver |
| Roof hatches | 2 roof hatches with ventilation |
